BEL Trainee Engineer CS Mock Test- 3 - Computer Science Engineering (CSE) MCQ

Characteristic equation:

|A − λI| = 0

⇒ (5 − λ)(3 − λ) − 3 = 0;

⇒ λ² − 8λ + 15 − 3 = 0

⇒ λ² − 8λ + 12 = 0

⇒ λ = 2,λ = 6

Eigenvector for λ = 2,

(A − 2I) × x = 0

At, λ = 2



⇒ 3x₁ + 3x₂ = 0;

⇒ x₁ = −x₂;

The eigenvector will be

So, the required vector is

Hence, the correct option is (B).

Three cases:

(i) Insertion at the beginning.

p → new node

q → first node

∴ p → R link = q

p → L link = NULL

q → L link = p

∴3 updations.

(ii) Insertions at end (q is the last node).

p → R link = NULL

p → L link = q

p → R link = p

∴ 3 updations.

(iii) Insertions in middle of q and r.

p → R link = r

p → L link = q

q → R link = p

r → L link = p

∴ 4 updations.

Hence, the correct option is (C).

We have

f(x) = logx/x

Differentiating with the help of Quotient rule we get,

For maxima or minima, f'(x) = 0

Again

As f"(e) < 0 at x = e , hence x = e is point of local maxima.

• Views in a database system are important because they help with access control by allowing users to see only a particular subset of the data in the database. (Correct)
• E-R diagrams are useful to logically model concepts. (Incorrect)
• An update anomaly is when it is not possible to store information unless some other, unrelated information is stored as well. (Incorrect)
• SQL is a procedural language. (Incorrect)

So, option (4) is correct.

S → ACB | cbB | Ba

A → da | BC

B → g|∈

C → h|∈

first (A) = first(da), first(BC)

first(da) = d

first(BC) = first(B)

= g, ∈ [since ∈ is in first (B)]

first (C) = h, ∈  [Now ∈ is part of C]

According to Rouche's theorem, the system is consistent if and only if the co-efficient matrix and the augmented matrix are of the same rank, otherwise the system is inconsistent.

Pole is z - 3j = 0

⇒ z = 3j

Residue at z = 3j is 2[(3j)² + 8] = -2

= 2πj x (-2) = -4πj

Abstraction, Encapsulation, Polymorphism and Inheritance are the essential features of a OOP Language.
Abstraction is used to hide the inner details of the data in the programming languages.
Abstract classes can be created using a programming language supporting OOPS.
Encapsulation is used to bind the data and functions together in the form of bundles.
Polymorphism is used to implement the functions having same signature but different functions.
Inheritance is implemented in the programs to inherit the properties of one class to the another class or objects. The concept of polymorphism is used in inheritance to reuse the functions or methods.
Hence, option 2 is correct.

Given,

Let x + a = t

x = t − a

dx = dt

As we know,

sin⁡(A + B) = sin⁡A cos⁡B + cos⁡A sin⁡B

= cos⁡ a ∫ dt − sin⁡ a ∫ cot ⁡tdt

= (cos ⁡a)t − (sin ⁡a) log⁡ | sin⁡ t | + C

= (cos⁡ a)(x + a) − (sin ⁡a) log ⁡|sin⁡(x + a)| + C

= x cos ⁡a + a cos ⁡a − (sin ⁡a) log ⁡| sin⁡(x + a) | − C

= x cos ⁡a − sin ⁡a log⁡ | sin⁡(x + a) | + C

Where C = C + a cos ⁡a, is another arbitrary constant.

Hence, the correct option is (D).

To determine which main memory block maps to set 13 in a 4-way set-associative cache, follow these steps:

• The cache size is 16 KB, with lines of 32 bytes.
• Calculate the number of cache lines:
  • 16 KB / 32 bytes = 512 lines.
• Determine the number of sets:
  • Since it's a 4-way set-associative cache, divide lines by 4:
    • 512 / 4 = 128 sets.

Cache representation:

• Physical memory size is 16 MB, requiring 24-bit addresses.
• Address partitioning:
  • Offset (5 bits), Index (7 bits), Tag (12 bits).
• To map to set 13:
  • Consider the index bits (b₁₁ to b₅).
  • For set 13, these bits must be 0001101.

Therefore, the correct memory block that maps to set 13 is option D.

The item can be pushed to stack and later popped and printed, or printed directly.
If 1, 2, 3, 4, 5 is the input, then (4) is not possible because once pushed, 1 is printed after 2.
Similarly, (1) and (2) are not possible.

Mean value theorem:
Suppose f(x) is a function that satisfies both of the following:
1. f(x) is continuous on the closed interval [a, b].
2. f(x)is differentiable on the open interval (a, b).
Then there is a number c such that a < c < b and f′(c) = (f(b) − f(a)) / (b − a)
Using Mean value theorem
⇒ c = log (e – 1)

Virtual (CPU) address has 32 bits.
2 way set associative cache size = 64 KB
Size of 1 set = 32 KB
We require 15 bits for indexing.
So, Tag = 32 - 15 = 17
Size of block = 16 bytes i.e. 4 bits are required
Index = block + word
Block = 15 - 4 = 11

CPV address

There are 2¹⁷ bytes of tags in every set of cache.
So, total = 17 × 2 × 1024 = 34 K bits

If there are n elements in the list, then (n - 1) passes are required to compare the elements in the first pass.

Thus, total number of comparisons (A) in bubble sort for a list of N elements = n - 1 = 7 - 1 = 6

In selection sort, selecting the lowest element requires n - 1 + n - 2 + n - 3 + ... comparisons for n elements.
B =  = 21
Hence, A < B

Only the statement "The only odd prime number is 2" has got the truth value which is false. A proposition is a collection of declarative statements that has either a truth value "true” or a truth value "false". A propositional consists of propositional variables and connectives. We denote the propositional variables by capital letters (A, B, etc). The connectives connect the propositional variables. A proposition is simply a statement.

Hence, the correct option is (D).

As we know that ,
Scrimp means to live on very little money and Lavish is to live extravagantly, i.e., spending a lot of money, parsimonious are means for making money.
Therefore , Lavish is opposite word of Scrimp .

The sentence "One cannot expect children to understand these problems" in the Active Voice can be accurately transformed into the Passive Voice as:

C. Children cannot be expected to understand these problems.

This option represents the same meaning as the original sentence in the Passive Voice.

The government got troubled because it lacks the independence of talking decisions. Because democracy does't allow to do so.

The government went ahead when it didn't get the support of BJP and the left.

The answer is (d) and it based on the information given in the passage.

Daunting means seeming difficult to deal with in prospect; intimidating
He loved undertaking daunting assignments
Army began a daunting operation to the flush out the terrorists

Answer:
Gateway is used to communicate between different networks. It acts as a bridge or translator between two different networks, allowing them to exchange data and communicate with each other.
Here is a detailed explanation:
What is a Gateway?
A gateway is a networking device that connects two or more networks together and facilitates communication between them. It serves as an entry or exit point for data traffic between different networks, allowing them to exchange information.
Function of a Gateway:
The main function of a gateway is to perform protocol conversion and data translation between different networks. It enables communication between networks that use different protocols, such as TCP/IP, Ethernet, or ATM.
Types of Gateways:
There are different types of gateways, including:
1. Network Gateway: Connects different types of networks, such as LAN (Local Area Network) and WAN (Wide Area Network).
2. Protocol Gateway: Translates data between different protocols, such as converting data from TCP/IP to IPX/SPX.
3. Application Gateway: Enables communication between different applications or services running on different networks.
4. Security Gateway: Provides security features such as firewall and VPN (Virtual Private Network) to protect the network from unauthorized access.
Advantages of using a Gateway:
1. Interoperability: Gateway allows different networks to communicate and exchange data seamlessly.
2. Protocol Conversion: It enables data translation between networks that use different protocols.
3. Security: Gateways can provide security features to protect the network from external threats.
4. Scalability: Gateways can be easily added or upgraded to accommodate the growing needs of the network.
In conclusion, a Gateway is used to communicate between different networks by acting as a bridge and facilitating data exchange between them. It plays a crucial role in enabling interoperability and ensuring smooth communication between networks that use different protocols.

Outputs needed by middle level managers:
- Summary reports with good grouping: Middle level managers require summary reports that provide a concise overview of key information, such as sales figures, production data, or project updates. These reports should be well-organized and grouped in a logical manner to facilitate understanding and decision-making.
- Exception reports: Middle level managers need exception reports that highlight any deviations, anomalies, or significant events that require attention. These reports help managers identify problems or areas of concern that may require further investigation or action.
- Detailed reports: Middle level managers may also require detailed reports that provide comprehensive information on specific aspects of their department or projects. These reports can include detailed financial statements, performance metrics, or project progress updates.
- Expected reports: Middle level managers may have specific reports that they expect on a regular basis. These reports may be customized to their needs and provide them with the necessary information to monitor and manage their department effectively.
Overall, the outputs needed by middle level managers should provide them with the necessary information to make informed decisions, monitor performance, and identify any issues or opportunities within their area of responsibility.

The correct answer is Expansion cards.

Key Points

• Expansion cards contain edge connectors that are used to enable communication between the motherboard and different card.​
  • It is an electronic card/board that adds extra functionality to a computer.
  • It is inserted into an expansion slot on the motherboard of a computer.

Additional Information

• ​A port is a physical docking point using which an external device can be connected to the computer.
• The system bus is the internal path from the CPU to memory.
  • It is split into address bus and data bus subsets.
  • Addresses are sent over the address lines to signal a memory location.
  • Data are transferred over the data lines to that location.
  • System buses transfer data in parallel. In a 32-bit bus, data are sent over 32 wires simultaneously.
• An expansion bay or bay is an open computer section used for expansion add-ons to your computer, such as a hard drive and CD-ROM drive.

The correct answer is option B: i and iii.
Explanation:
- A line printer prints an entire line at a time, which means it prints all the characters in a line simultaneously.
- It allows multiple copies to be taken at a time, which means it can print multiple copies of the same line without having to print each copy separately.
- However, a line printer is an impact printer, not a non-impact printer. Impact printers use a mechanism that physically strikes an inked ribbon against the paper to create an image, whereas non-impact printers use methods like heat or lasers to transfer the image onto the paper.
- Lastly, a line printer does not print one character at a time. It prints an entire line, not individual characters.
To summarize, a line printer prints an entire line at a time and allows multiple copies to be taken at once. Therefore, the correct answer is option B: i and iii.

The correct answer is 1024.

Key Points

• One gigabyte in the memory context of data storage comprises 1024 MB (megabyte) or 1 million bytes.
• In SI units, it is written as 109. This is the most commonly used unit of storage in modern times.

Additional Information

•  Unit Conversion Table:
  • 4 bit = 1 Nibble
  • 8 bit = 1 byte
  • 1 KB (kilobyte) = 1024 byte
  • 1 MB (megabyte) = 1024 KB
  • 1 GB (gigabyte) = 1024 MB
  • 1 TB (terabyte) = 1024 GB
  • 1 PB (petabyte) = 1024 TB
  • 1 XB (Exabyte) = 1024 PB
  • 1 ZB (zettabyte) = 1024 XB
  • 1 YB (yottabyte) = 1024 ZB

As per the given information;

Distance between S and P = √(PQ² + QS²)
SP = √(6² + 8²)
SP = √(36 + 64)
SP = √100
SP = 10 km
Hence, S is 10 km in South-East with respect to P.

From the common explanation, we get the immediate neighbour of P and M is Q.

Hence, Option C is correct.

Final Arrangement:

Common Explanation:

References:

M is sitting fourth to the right of N.

P is sitting second to the left of N.

Inferences:

From the above reference, we get the following arrangements:

References:

Q is sitting third to the right of S.

Inferences:

From the above reference, we get two different cases:

Case 1:

Case 2:

References:

S is not sitting beside P.

T is sitting second to the left of O.

O is not sitting beside M.

Inferences:

So, from this case 1 will be eliminated as S is not sitting beside P.

Thus, the final arrangement,

To solve the analogy problem where the pattern needs to be identified, let’s break it down step-by-step:

The analogy given is: 16 : 56 :: 32 : ?

We need to find the relationship between the numbers 16 and 56 and then apply that relationship to 32 to find the missing number.

1. Find the relationship between 16 and 56:

   • Step 1: Check the operations or patterns. Consider possible operations like addition, subtraction, multiplication, or division.

   • Step 2: Test if multiplication could be a pattern:

     16×3.5=56

     This works as:

     16×3.5=56

     Thus, multiplying by 3.5 seems to be the pattern.

2. Apply the same pattern to 32:

   32×3.5=112

   Therefore, according to this pattern, the number that replaces the question mark should be 112.

3. Verify the other options:

   • 96: This is much larger than expected.
   • 112: Also too large.
   • 121: Similarly, too large.
   • 128: While close, it’s not the result from our multiplication pattern.

Hence, the correct answer is:

112

As 'Flower' is made from 'Bud' similarly 'Fruit' is made from 'Flower'.
