GATE Mock Test Electronics Engineering (ECE)- 9 - Electronics and Communication Engineering (ECE) MCQ


Test Description

30 Questions MCQ Test - GATE Mock Test Electronics Engineering (ECE)- 9

GATE Mock Test Electronics Engineering (ECE)- 9 for Electronics and Communication Engineering (ECE) 2024 is part of Electronics and Communication Engineering (ECE) preparation. The GATE Mock Test Electronics Engineering (ECE)- 9 questions and answers have been prepared according to the Electronics and Communication Engineering (ECE) exam syllabus.The GATE Mock Test Electronics Engineering (ECE)- 9 MCQs are made for Electronics and Communication Engineering (ECE) 2024 Exam. Find important definitions, questions, notes, meanings, examples, exercises, MCQs and online tests for GATE Mock Test Electronics Engineering (ECE)- 9 below.
Solutions of GATE Mock Test Electronics Engineering (ECE)- 9 questions in English are available as part of our course for Electronics and Communication Engineering (ECE) & GATE Mock Test Electronics Engineering (ECE)- 9 solutions in Hindi for Electronics and Communication Engineering (ECE) course. Download more important topics, notes, lectures and mock test series for Electronics and Communication Engineering (ECE) Exam by signing up for free. Attempt GATE Mock Test Electronics Engineering (ECE)- 9 | 65 questions in 180 minutes | Mock test for Electronics and Communication Engineering (ECE) preparation | Free important questions MCQ to study for Electronics and Communication Engineering (ECE) Exam | Download free PDF with solutions
GATE Mock Test Electronics Engineering (ECE)- 9 - Question 1
Save

A invest 1/3 part of the capital for 1/6 of the time, B invest 1/4 part of the capital for 1/2 of the time and C invest rest of the capital for rest of the time. Out of a profit of Rs. 23000, B’s share is?

Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 1
Raio of their Investment

= 4 : 9 : 10

B’s share = 23000 x 9/23 = Rs.9000

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 2
Save

Pick the odd one out.

Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 2
Swimming is done in a large water body. All the other words relate to activities involving smaller volume of water.
1 Crore+ students have signed up on EduRev. Have you? Download the App
GATE Mock Test Electronics Engineering (ECE)- 9 - Question 3
Save

In the following question, out of the four alternatives, select the word opposite in meaning to the given word.

Gratuitous

Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 3
The word “gratuitous” means given or done free of charge. Thus, the word “costly” would be the correct antonym of the given word.

Gratis means without charge; free. Thus, option B is the correct answer.

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 4
Save

Pick the odd one out.
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 4
Break, hiatus and pause, all mean a temporary halt. End is the final halt.
GATE Mock Test Electronics Engineering (ECE)- 9 - Question 5
Save

The bar graph shows the number of employees working under the six different Departments (A, B, C, D, E, F) of a certain company. Study the diagram and answer the following questions.

If departments F and D are merged to create a new department G, then which department will have the least number of employees?
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 5

If departments F and D are merged to create a new department G, then

Employees in department A = 25

Employees in department B = 6

Employees in department C = 10

Employees in department E = 15

Employees in department G = 8

∴ Department B has the least number of employees

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 6
Save

Fill in the missing number in the series:

7, 13, 21, ____, 43, 57
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 6
In this series, each subsequent term is obtained by adding 6, 8, 10, 12, 14,... respectively in the previous term. Hence, the missing term is 21 + 10 = 31.
GATE Mock Test Electronics Engineering (ECE)- 9 - Question 7
Save

A sum of Rs.400 amounts to Rs.480 in 4 years. What will it amount to if the rate of interest is increased by 2 % for the same time?
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 7

We know that,

A = S.I + P

480 = S.I + 400

⟹ S.I = 480 – 400 = 80

⟹ S.I =

⟹ 80 =

⟹ R = 5 %

Now rate is increased by 2 %

So, new rate is 7%

New S.I = = Rs. 112

New Amount = S.I + P = 112 + 400 = Rs.512

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 8
Save

How many times do the hands of a clock overlap in 24 hours?
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 8
After 11 o'clock, the minute hand has to travel all the way and by the time they meet it is has to be 12 o'clock again, since we know what the clock looks like at that time. So the two hands overlap 11 times in a 12 hour period. So, in a 24 hour period, they would overlap 22 times.
GATE Mock Test Electronics Engineering (ECE)- 9 - Question 9
Save

In the following question, some part of the sentence may have errors. Find out which part of the sentence has an error and select the appropriate option. If the sentence is free from error, select 'No error'.

The gold foil used liberal (1)/ in Thanjavur paintings serves (2)/ many objectives that makes the painting more attractive. (3)/ No error
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 9
The error is in part (1) of the sentence. Change ‘liberal’ to ‘liberally’ because in this sentence it is in adjective form while the proper usage of liberal is in its adverb form i.e. ‘liberally’ as it qualifies the gold foil here.
GATE Mock Test Electronics Engineering (ECE)- 9 - Question 10
Save

In the following question, a group of four figures following certain sequence is given as problem figures. Problem figures are followed by another group of four figures known as answer figures marked (1), (2), (3), (4). Find out the figure from the answer figures which when placed next to the problem figures will continue the sequence of the problem figures.
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 10
In going from one problem figure to the next, the arrows are going from vertical to horizontal and one arrow decreases in number.

Then they again go back to vertical.

Answer figure (3) will continue the sequence of the problem figures.

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 11
Save

During transmitting over a binary communication channel, bit error occurs independently with a probability of p. The probability of at most 2 bits in error in a block of ‘n’ transmitted bits would be
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 11
Probability of no error = (1 - p)n

Probability of single bit in error = nC1p(1 - p)n-1

Probability of 2 bits in error = nC2p2(1 - p)n-2

Thus, total probability= (1 - p)n

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 12
Save

There are 60 students in a class. The students are divided into three groups A, B and C of 15, 20 and 25 students, respectively. The groups A and C are combined to form group D. What is the average weight of the students in group D?
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 12
There is no indication of weights of the students in the question. Therefore, it is not possible to find the relation between the weights of students in groups A, B, C, and D.
GATE Mock Test Electronics Engineering (ECE)- 9 - Question 13
Save

Transfer function of an LTI system is given as G(S)= (s-1)/(s+1)

Find the gain of the system at a frequency of 1 rad/s.
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 13

We have, putting s=jω G(jω)=

= 1

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 14
Save

The probability that a man will live 10 more years is 1/4 and the probability that his wife will live 10 more years is 1/3. The probability that neither of them will be alive in 10 years is
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 14
Probability that a man will live 10 more years = 1/4

Probability that man will not live 10 more years = 1 - 1/4 = 3/4

Probability that his wife will live 10 more years = 1/3

Probability that his wife will not live 10 more years = 1 - 1/3 = 2/3

Then, probability that neither will be alive in 10 years = (3/4) x (2/3) = 1/2

*Answer can only contain numeric values
GATE Mock Test Electronics Engineering (ECE)- 9 - Question 15
Save

Consider the Schmitt trigger circuit shown below the Hysteresis width in Volts is……?

Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 15
Apply KCL at Va

When V0 = +VsatV2 = VUTP

When V0 = +VsatVa = VLTP

Here Vref = -10

R1 = 10k,

R2 = 50k,

R3 = 10k

VUTP =

= - 3.4545V

Similarly VLTP = -5.6363

So hyseresis width

= UTP - LTP

= (-3.4545) - (5.6363)

= 2.19V

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 16
Save

Voting is the privilege for which wars have been fought, protests have been organized, and editorials have been written. "No taxation without representation," was a battle cry of the American Revolution. Women struggled for suffrage, as did many minorities. Eighteen year olds clamored for the right to vote, saying that if they were old enough to fight in the war, then they should be allowed to vote. Yet Americans have a deplorable voting history, and many will tell you that they have never voted.

Which of the following words is the best synonym for the word 'privilege' as used in the passage?
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 16
The context mentions that wars have been fought for 'voting' and 'privilege' means 'a special right'.
GATE Mock Test Electronics Engineering (ECE)- 9 - Question 17
Save

A non-ideal diode is used in a clamper circuit. The forward and reverse resistances of the diode are 200 ohms and 250 kilo ohms, respectively. The circuit designer has designed the circuit using a 10 kilo ohm resistor. The value of resistor to be connected in parallel to correct the circuit would be approximately
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 17
We have a formula to get the value of resistor to be used in a clamper circuit and it is given by R =

This gives value of R as 7.07 kΩ.

Since 10 kΩ resistor is being used, to make effective resistance as 7.07 kΩ, a resistor of value 24.18 kΩ has to be connected in parallel.

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 18
Save

Two trains start at the same time from two stations A and B towards each other.

They arrive at B and A respectively in 5 hours and 20 hours after they passed each other.

If the speed of the train that started from A is 56 kmph, then what is the speed of the second train (in kmph)?
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 18
Let the speeds of two trains starting from station A and B be S1 and S2 respectively and the time taken by them after meeting be t1 and t2 respectively.

Then, we can use this equation to get the answer:

S2 = 28 kmph

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 19
Save

If a characteristics equation has roots S = -3 ± J4 then the values of natural frequency and damping ratio will be respectively.
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 19

We know that S =

Thus, option c is correct answer.

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 20
Save

A man starts at a certain point, walks one km east, then two km north, one km east, one km north, one km east and finally one km north to arrive at the destination. What is the shortest distance (in km) from the starting point to the destination?
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 20

Let us assume that man starts from point O and reaches his destination at point A.

The shortest distance between O and his destination is OA = = 5 km

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 21
Save

Calculate value of RL so that maximum power is transmitted through RL Also calculate maximum power generated
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 21

To find RL

For maximum power transfer RL = RS

All voltage sources should be short circuited and current sources should be open circuited and RL should be removed.

Consider the figure:

RS = 5|| 10 = 50/15 =3.33 Ω

Therefore RL = 3.33 Ω

To calculate power generated:

R= 5 + 3.33||10 = 7.5 Ω

I=V/R =10/7.5 = 1.33 A

Iab= 1.33×10/(10+3.33) = 1A

P = I2 RL = (1.33)2 × 3.33 =5.8 W

Thus, option D is the correct answer.

*Answer can only contain numeric values
GATE Mock Test Electronics Engineering (ECE)- 9 - Question 22
Save

If u = log , find the value of x .(Answer up to the nearest integer)

Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 22

On solving, we get

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 23
Save

Find the transfer function for the given block diagram?
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 23

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 24
Save

If the closed-loop transfer function of a control system is given as T(s) = then it is
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 24
In a minimum phase system, all the poles as well as zeros are on the left half of the s-plane. In given system, as there is right half zero (s = 5), the system is a non-minimum phase system.
GATE Mock Test Electronics Engineering (ECE)- 9 - Question 25
Save

For the n-channel enhancement MOSFET shown in the given figure, Threshold voltage Vtn=2V,The drain current ID of the MOSFET is 4mA when drain resistance RD is 1kΩ, If value of RD is increase to 4kΩ, then drain current ID will become
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 25
ID=K(VGS-V(E(th)2

4mA=K(VGS-2)2

Here VGS=10-4×1=6

∴4=k(6-2)2

K= 4/16=¼

When RD is increased to 4kΩ.

VGS=10-4ID

Now ID= 4/16(10-4ID-2)2

Solving the above equation for ID we will get

ID =2.8 mA and ID =1.4 mA and

but ID can not be 2.8 mA as VGS becomes negative so,

ID =1.4 mA

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 26
Save

The root locus of the system G(s) H(s) = has the break-away point located at
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 26

Since, breakpoint must lie on root locus. So, s = -0.784 is possible.

*Answer can only contain numeric values
GATE Mock Test Electronics Engineering (ECE)- 9 - Question 27
Save

As it comes in the form of 0/0 so applying LH rule QUESTION IS DISPLACED

Putting t=1/4W

P (t) = = 0.5

Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 27
fm=3.4kHz

fs=8kHz

Qs=64

⇒2n=64

⇒∩=no.of bits=6

m=10

Total bits in a frame =nm+5/2

(As extra bit is added after every alternate frame)

=6×10+2.5

=62.5bits

Bit rate, rb total bits in a frame × sampling frequency

=62.5×8000

=5×105bits/sec

∴Minimum channel bandwidth,

BW = rb/2 = 2.5 x 105

= 0.25 х 105

= 0.25 x MHz

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 28
Save

A conducting circular loop of radius 20 cm lies in the z = 0 plane in a field B = 20 cos 377t az mWb/m2. The induced voltage in the loop is
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 28

*Answer can only contain numeric values
GATE Mock Test Electronics Engineering (ECE)- 9 - Question 29
Save

The transfer function of a network can be written as

(1+s)/(1+0.5s) . The maximum phase angle occurs at a frequency of _______ rad/sec.

Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 29
Comparing with standard transfer function

Here, τ=1

and aτ=0.5

or a=0.5

∵ α< />

∴ Lead network

The maximum phase occurs at a frequency of

ωm=

= 2rad/sec

GATE Mock Test Electronics Engineering (ECE)- 9 - Question 30
Save

If v = 2xy, then the analytic function f (z) = u + iv is
Detailed Solution for GATE Mock Test Electronics Engineering (ECE)- 9 - Question 30

By Milne's Method, f'(z) = g(z,0) + ih(z,0) = 2z + i0 = 2z

On intergrating, f(z) = z2 + c

View more questions
Information about GATE Mock Test Electronics Engineering (ECE)- 9 Page
In this test you can find the Exam questions for GATE Mock Test Electronics Engineering (ECE)- 9 solved & explained in the simplest way possible. Besides giving Questions and answers for GATE Mock Test Electronics Engineering (ECE)- 9, EduRev gives you an ample number of Online tests for practice

Top Courses for Electronics and Communication Engineering (ECE)

Download as PDF

Top Courses for Electronics and Communication Engineering (ECE)

Important Questions for GATE Mock Test Electronics Engineering (ECE)- 9

Find all the important questions for GATE Mock Test Electronics Engineering (ECE)- 9 at EduRev.Get fully prepared for GATE Mock Test Electronics Engineering (ECE)- 9 with EduRev's comprehensive question bank and test resources. Our platform offers a diverse range of question papers covering various topics within the GATE Mock Test Electronics Engineering (ECE)- 9 syllabus. Whether you need to review specific subjects or assess your overall readiness, EduRev has you covered. The questions are designed to challenge you and help you gain confidence in tackling the actual exam. Maximize your chances of success by utilizing EduRev's extensive collection of GATE Mock Test Electronics Engineering (ECE)- 9 resources.

GATE Mock Test Electronics Engineering (ECE)- 9 MCQs with Answers

Prepare for the GATE Mock Test Electronics Engineering (ECE)- 9 within the Electronics and Communication Engineering (ECE) exam with comprehensive MCQs and answers at EduRev. Our platform offers a wide range of practice papers, question papers, and mock tests to familiarize you with the exam pattern and syllabus. Access the best books, study materials, and notes curated by toppers to enhance your preparation. Stay updated with the exam date and receive expert preparation tips and paper analysis. Visit EduRev's official website today and access a wealth of videos and coaching resources to excel in your exam.

Online Tests for GATE Mock Test Electronics Engineering (ECE)- 9

Practice with a wide array of question papers that follow the exam pattern and syllabus. Our platform offers a user-friendly interface, allowing you to track your progress and identify areas for improvement. Access detailed solutions and explanations for each test to enhance your understanding of concepts. With EduRev's Online Tests, you can build confidence, boost your performance, and ace GATE Mock Test Electronics Engineering (ECE)- 9 with ease. Join thousands of successful students who have benefited from our trusted online resources.
© EduRev
Education Revolution
Follow Us
Signup to see your scores go up within 7 days!
Access 1000+ FREE Docs, Videos and Tests
Takes less than 10 seconds to signup
