All questions of Circles for Class 10 Exam
In Fig. 8.6, if PA and PB are tangents to the circle with centre O such that ∠APB = 50°, then ∠PAB is equal to
- a)35°
- b)65°
- c)40°
- d)70°
Correct answer is option 'B'. Can you explain this answer?
In Fig. 8.6, if PA and PB are tangents to the circle with centre O such that ∠APB = 50°, then ∠PAB is equal to
a)
35°
b)
65°
c)
40°
d)
70°
|
Crafty Classes answered |
In triangle PAB
∠A+∠B+∠P=180
x+x+50=180 [ if tangents are drawn from same point then they are equal so PAB is a isoceles triangle ]
2x=130
x=65
∠A+∠B+∠P=180
x+x+50=180 [ if tangents are drawn from same point then they are equal so PAB is a isoceles triangle ]
2x=130
x=65
A circle can pass through
- a)2 collinear points
- b)3 collinear points
- c)4 collinear points
- d)4 collinear points
Correct answer is option 'A'. Can you explain this answer?
A circle can pass through
a)
2 collinear points
b)
3 collinear points
c)
4 collinear points
d)
4 collinear points
|
Krishna Iyer answered |
The answer can be 2 collinear points as well. We have three collinear points. Join one point to the other two points and then draw the perpendicular bisector for both the lines
Join the perpendicular bisectors. The point is the centre of the circle. And a circle can be formed then. Also two points can form a circle as the two points joines becomes a diameter.
Join the perpendicular bisectors. The point is the centre of the circle. And a circle can be formed then. Also two points can form a circle as the two points joines becomes a diameter.
Option D : The number of circles which can pass through three given non-collinear points is exactly one.
So, A is the correct Option
A circle touches x-axis at A and y-axis at B. If O is origin and OA = 5 units, then diameter of the circle is- a)8 units
- b)10 units
- c)
- d)
Correct answer is option 'B'. Can you explain this answer?
A circle touches x-axis at A and y-axis at B. If O is origin and OA = 5 units, then diameter of the circle is
a)
8 units
b)
10 units
c)
d)
|
Skyhigh Academy answered |
OA = OB ⇒ OB = 5
AC = BC [Radii]
⇒ OACB is a square.
⇒ AC = OA = 5
⇒ Diameter =10 units.
AC = BC [Radii]
⇒ OACB is a square.
⇒ AC = OA = 5
⇒ Diameter =10 units.
In fig., two circles with centres A and B touch each other externally at k. The length of PQ (in cm) is
- a)24 cm
- b)20 cm
- c)27 cm
- d)18 cm
Correct answer is option 'C'. Can you explain this answer?
In fig., two circles with centres A and B touch each other externally at k. The length of PQ (in cm) is
a)
24 cm
b)
20 cm
c)
27 cm
d)
18 cm
|
Vikas Kumar answered |
Constructions - join AS and join BT.
Case 1 (triangle ASP)
We know, ∠ASP = 900 (radius is perpendicular to tangent at point of contact)
So, in triangle ASP,
AP2 = PS2 + AS2
=> 132 = 122 + AS2
=> 169 = 144 + AS2
+> AS2 = 169 - 144 = 25
=> AS = √25 = 5cm
Since AS is radius, AP = Ak = 5 cm.
Case 2 (triangle BTQ)
We know, ∠BTQ = 900 (radius is perpendicular to tangent at point of contact)
So, in triangle BTQ,
BQ2 = QT2 + BT2
= 52 = 32 + BT2
=> 25 = 9 + BT2
=> BT2 = 25 - 9 = 9
=> BT = √16 = 4cm
Since BT is radius, BT = Bk 4cm
Now, PQ = AP + Ak + Bk + BQ
=> PQ = 13 + 5 + 4 + 5
=> PQ = 27 cm
In the given figure, PQ is the tangent of the circle. Line segment PR intersects the circle at Nand R. PQ = 15 cm, PR = 25 cm, find PN:
- a)15 cm
- b)10 cm
- c)9 cm
- d)6 cm
Correct answer is option 'C'. Can you explain this answer?
In the given figure, PQ is the tangent of the circle. Line segment PR intersects the circle at Nand R. PQ = 15 cm, PR = 25 cm, find PN:
a)
15 cm
b)
10 cm
c)
9 cm
d)
6 cm
|
Archana singh answered |
Given, PQ = 15 cm
PR = 25 cm
We know that, PQ² = PN × PR
15² = PN × 25
225 = PN × 25
PN = 9
15² = PN × 25
225 = PN × 25
PN = 9
Two parallel lines touch the circle at points A and B respectively, If area of the circle is 25πcm2, then AB is equal to- a)5 cm
- b)8 cm
- c)10 cm
- d)25 cm
Correct answer is option 'C'. Can you explain this answer?
Two parallel lines touch the circle at points A and B respectively, If area of the circle is 25πcm2, then AB is equal to
a)
5 cm
b)
8 cm
c)
10 cm
d)
25 cm
|
|
Vivek Rana answered |
Let radius of circle = R
∴ πR2 = 25π
⇒ R = 5cm
∴ Distance between two parallel tangents
= diameter = 2 x 5 = 10 cm.
∴ πR2 = 25π
⇒ R = 5cm
∴ Distance between two parallel tangents
= diameter = 2 x 5 = 10 cm.
The length of the tangent drawn from a point 8 cm away from the centre of a circle of radius 6 cm is- a)√7 cm
- b)2√7 cm
- c)10 cm
- d)5 cm
Correct answer is option 'B'. Can you explain this answer?
The length of the tangent drawn from a point 8 cm away from the centre of a circle of radius 6 cm is
a)
√7 cm
b)
2√7 cm
c)
10 cm
d)
5 cm
|
Pooja Shah answered |
Let P be the external point and PA and PB be the tangents and OA and OB be the radii.
So OP is the hypotenuse=8cm
Applying Pythagoras theorem,
H2 = P2 + B2
64 = AP2 + 36
AP =
So OP is the hypotenuse=8cm
Applying Pythagoras theorem,
H2 = P2 + B2
64 = AP2 + 36
AP =
A tangent PA is drawn from an external point P to a circle of radius 3√2 cm such that the distance of the point P from O is 6 cm as shown figure. The value of ∠APO is
- a)30°
- b)60°
- c)45°
- d)75°
Correct answer is option 'C'. Can you explain this answer?
A tangent PA is drawn from an external point P to a circle of radius 3√2 cm such that the distance of the point P from O is 6 cm as shown figure. The value of ∠APO is
a)
30°
b)
60°
c)
45°
d)
75°
|
Sushil Kumar answered |
The correct answer is c
In right angled triangle, OAP
sin of angle APO = AO/OP = 1/root2
sin 45 = 1/root2
angle APO = 45 degree
In the given figure, AR=5cm, BR=4cm and AC =11cm. What is the length of BC?
- a)6 cm
- b)10 cm
- c)4 cm
- d)8 cm
Correct answer is option 'B'. Can you explain this answer?
In the given figure, AR=5cm, BR=4cm and AC =11cm. What is the length of BC?
a)
6 cm
b)
10 cm
c)
4 cm
d)
8 cm
|
|
Vivek Rana answered |
Since the sides of the triangles are tangent to the circle. BR = BP,AR = AQ and CP = CQ
So, BP = 4cm and AQ = 5
CQ = 11-5 = 6 = CP
BC = BP + CP = 4 + 6 = 10 cm
So, BP = 4cm and AQ = 5
CQ = 11-5 = 6 = CP
BC = BP + CP = 4 + 6 = 10 cm
At point A on a diameter AB of a circle of radius 10 cm, tangent XAY is drawn to the circle. The length of the chord CD parallel to XY at a distance 16 cm from A is- a)8 cm
- b)10 cm
- c)16 cm
- d)18 cm
Correct answer is option 'C'. Can you explain this answer?
At point A on a diameter AB of a circle of radius 10 cm, tangent XAY is drawn to the circle. The length of the chord CD parallel to XY at a distance 16 cm from A is
a)
8 cm
b)
10 cm
c)
16 cm
d)
18 cm
|
Aditya Shah answered |
In the given figure
XY is the tangent to the circle
We know that tangent is at right angle with the line joining the tangent point to the centre of the circle
Therefore,
∠OAY = 90°
∵ CD is parallel to XY
Therefore,
∠OAY = ∠BED = 90° (Corresponding angles)
Again,
Given that
AE = 16 cm
And the radius of the circle is 10 cm
Therefore,
AO = 10 cm
∴ OE = AE - AO = 16 - 10 = 6 cm
Also,
OC = 10 cm (Radius of the circle)
In fig, O is the centre of the circle, CA is tangent at A and CB is tangent at B drawn to the circle. If ∠ACB = 75°, then ∠AOB =
- a)75°
- b)85°
- c)95°
- d)105º
Correct answer is option 'D'. Can you explain this answer?
In fig, O is the centre of the circle, CA is tangent at A and CB is tangent at B drawn to the circle. If ∠ACB = 75°, then ∠AOB =
a)
75°
b)
85°
c)
95°
d)
105º
|
|
Kuldeep Kuldeep answered |
Solution:- The length of tangents drawn from an external point to the circle are equal.
In the figure, CA and CB are the tangents from external point of a circle and OA and OB are the two radius of a circle.
Draw a line OC, then you will get two triangles OAC and OBC.
In a ∆le AOC and ∆le BOC,
Angle OAC and OBC = 180 degree. Because, these are angles between the radii and tangents. So, there are two right angles.
The value for right angled triangle is 90 degree. Here, you can see both right angled triangle, so 90×2 = 180 degree.
Angle AOB = Angle OAC + Angle OBC - Angle ACB.
Given:- Angle ACB = 75 degree. , Angle OAC and OBC = 90 degree.
Angle AOB = 90 + 90 - 75.
Angle AOB = 180 -75.
Angle AOB =105 degree.
So, option d is correct friend.
In the figure, CA and CB are the tangents from external point of a circle and OA and OB are the two radius of a circle.
Draw a line OC, then you will get two triangles OAC and OBC.
In a ∆le AOC and ∆le BOC,
Angle OAC and OBC = 180 degree. Because, these are angles between the radii and tangents. So, there are two right angles.
The value for right angled triangle is 90 degree. Here, you can see both right angled triangle, so 90×2 = 180 degree.
Angle AOB = Angle OAC + Angle OBC - Angle ACB.
Given:- Angle ACB = 75 degree. , Angle OAC and OBC = 90 degree.
Angle AOB = 90 + 90 - 75.
Angle AOB = 180 -75.
Angle AOB =105 degree.
So, option d is correct friend.
If PA and PB are tangents to the circle with centre O such that ∠APB = 40∘, then ∠OAB is equal to
- a)30∘
- b)40∘
- c)25∘
- d)20∘
Correct answer is option 'D'. Can you explain this answer?
If PA and PB are tangents to the circle with centre O such that ∠APB = 40∘, then ∠OAB is equal to
a)
30∘
b)
40∘
c)
25∘
d)
20∘
|
Parth Basu answered |
Let ∠OAB = ∠OBA = x [Opposite angles of opposite equal radii] And ∠AOB =180° - 40° = 140°
Now, in triangle AOB,
∠OAB + ∠OBA + ∠AOB = 180°
⇒ x + x +140° = 180°
⇒ 2x = 40°
⇒ x = 20°
∴ ∠OAB = 20°
Now, in triangle AOB,
∠OAB + ∠OBA + ∠AOB = 180°
⇒ x + x +140° = 180°
⇒ 2x = 40°
⇒ x = 20°
∴ ∠OAB = 20°
A circle may have…….- a)2 tangent
- b)1 tangent
- c)Infinite tangents
- d)No tangent
Correct answer is option 'C'. Can you explain this answer?
A circle may have…….
a)
2 tangent
b)
1 tangent
c)
Infinite tangents
d)
No tangent
|
|
Vedashree V answered |
Because a tangent intersect only one point on circle so it can form infinite tangents
If figure 1, O is the centre of a circle, PQ is a chord and PT is the tangent at P. If ∠POQ = 70o, then ∠TPQ is equal to
- a)45°
- b)5°
- c)35°
- d)70°
Correct answer is 'C'. Can you explain this answer?
If figure 1, O is the centre of a circle, PQ is a chord and PT is the tangent at P. If ∠POQ = 70o, then ∠TPQ is equal to
a)
45°
b)
5°
c)
35°
d)
70°
|
|
Ananya Das answered |
POQ is an isosceles triangle because of 2 radii as sides. So by angle sum property, 2*angle OPQ=180-70=110
Angle OPQ=55°
Since Angle TPO is a right angle , because PT is a tangent,
Angle OPQ+Angle TPQ=90
Angle TPQ=90° - 55° = 35°
Angle OPQ=55°
Since Angle TPO is a right angle , because PT is a tangent,
Angle OPQ+Angle TPQ=90
Angle TPQ=90° - 55° = 35°
From a point P which is at a distance of 13 cm from the centre O of a circle of radius 5 cm, the pair of tangents PQ and PR to the circle are drawn. Then the area of the quadrilateral PQOR is- a)60 cm2
- b)65 cm2
- c)30 cm2
- d)32.5 cm2
Correct answer is option 'A'. Can you explain this answer?
From a point P which is at a distance of 13 cm from the centre O of a circle of radius 5 cm, the pair of tangents PQ and PR to the circle are drawn. Then the area of the quadrilateral PQOR is
a)
60 cm2
b)
65 cm2
c)
30 cm2
d)
32.5 cm2
|
|
Krishna Iyer answered |
In figure AT is a tangent to the circle with centre O such that OT = 4 cm and ∠OTA = 30°. Then AT is equal to
- a)4 cm
- b)2 cm
- c)2√3 cm
- d)4√3 cm
Correct answer is option 'C'. Can you explain this answer?
In figure AT is a tangent to the circle with centre O such that OT = 4 cm and ∠OTA = 30°. Then AT is equal to
a)
4 cm
b)
2 cm
c)
2√3 cm
d)
4√3 cm
|
Ashwani Mishra answered |
∠OAT = 90° [∵ Tangent and radius are ⊥ to each other at the point of contact
In right-angle ΔOAT
The length of the tangent drawn from a point 8 cm away from the centre of a circle, of radius 6 cm, is :- a)10 cm
- b)5 cm
- c)√7 cm
- d)2√7 cm
Correct answer is option 'D'. Can you explain this answer?
The length of the tangent drawn from a point 8 cm away from the centre of a circle, of radius 6 cm, is :
a)
10 cm
b)
5 cm
c)
√7 cm
d)
2√7 cm
|
Dronacharya Institute answered |
Since tangent is perpendicular to radius, the triangle so formed is a right angled triangle,
So using Pythagoras Theorem,
Line joining centre and And the point outside the circle is hypotenuse and tangent and radius are the two sides
H2=P2+B2
64=P2+36
P=
So using Pythagoras Theorem,
Line joining centre and And the point outside the circle is hypotenuse and tangent and radius are the two sides
H2=P2+B2
64=P2+36
P=
How many tangents can be drawn to a circle from a point in its interior?- a)One
- b)Two
- c)infinite
- d)None
Correct answer is option 'D'. Can you explain this answer?
How many tangents can be drawn to a circle from a point in its interior?
a)
One
b)
Two
c)
infinite
d)
None
|
Shiva Tiwari answered |
Tangent can only be drawn from outside.and from a point outside the circle only two tangent can be drawn
Practice Test/Quiz or MCQ (Multiple Choice Questions) with Solutions of Chapter "Circles" are available for CBSE Class 10 Mathematics (Maths) and have been compiled as per the syllabus of CBSE Class 10 Mathematics (Maths)Q. A point P is 10 cm from the centre of a circle. The length of the tangent drawn from P to the circle is 8 cm. The radius of the circle is equal to- a)4 cm
- b)5 cm
- c)6 cm
- d)None of these.
Correct answer is option 'C'. Can you explain this answer?
Practice Test/Quiz or MCQ (Multiple Choice Questions) with Solutions of Chapter "Circles" are available for CBSE Class 10 Mathematics (Maths) and have been compiled as per the syllabus of CBSE Class 10 Mathematics (Maths)
Q. A point P is 10 cm from the centre of a circle. The length of the tangent drawn from P to the circle is 8 cm. The radius of the circle is equal to
a)
4 cm
b)
5 cm
c)
6 cm
d)
None of these.
|
|
Krishna Iyer answered |
ΔPTO is a right angled triangle at T ,where the tangent touches the circle.
So applying pythagoras theorem,
H2=P2+B2
102=B2+82
B=
Radius is 6cm.
So applying pythagoras theorem,
H2=P2+B2
102=B2+82
B=
Radius is 6cm.
In Fig. 8.4, the pair of tangents AP and AQ drawn from an external point A to a circle with centre O are perpendicular to each other and length of each tangent is 5 cm. Then radius of the circle is
- a)10 cm
- b)7.5 cm
- c)5 cm
- d)2.5 cm
Correct answer is option 'C'. Can you explain this answer?
In Fig. 8.4, the pair of tangents AP and AQ drawn from an external point A to a circle with centre O are perpendicular to each other and length of each tangent is 5 cm. Then radius of the circle is
a)
10 cm
b)
7.5 cm
c)
5 cm
d)
2.5 cm
|
Zachary Foster answered |
If the diagonals of a cyclic quadrilateral are equal, then the quadrilateral is- a)rhombus
- b)square
- c)rectangle
- d)none of these
Correct answer is option 'C'. Can you explain this answer?
If the diagonals of a cyclic quadrilateral are equal, then the quadrilateral is
a)
rhombus
b)
square
c)
rectangle
d)
none of these
|
|
Raghav Bansal answered |
Let ABCD be a cyclic quadrilateral having diagonals BD and AC, intersecting each other at point O.
(Consider BD as a chord)
∠BCD + ∠BAD = 180 (Cyclic quadrilateral)
∠BCD = 180− 90 = 90
(Considering AC as a chord)
∠ADC + ∠ABC = 180 (Cyclic quadrilateral)
90+ ∠ABC = 180
∠ABC = 90
Each interior angle of a cyclic quadrilateral is of 90.Hence it is a rectangle.
(Consider BD as a chord)
∠BCD + ∠BAD = 180 (Cyclic quadrilateral)
∠BCD = 180− 90 = 90
(Considering AC as a chord)
∠ADC + ∠ABC = 180 (Cyclic quadrilateral)
90+ ∠ABC = 180
∠ABC = 90
Each interior angle of a cyclic quadrilateral is of 90.Hence it is a rectangle.
From a point A, the length of a tangent to a circle is 8cm and distance of A from the circle is 10cm. The length of the diameter of the circle is
- a)6 cm
- b)12 cm
- c)16 cm
- d)14 cm
Correct answer is option 'B'. Can you explain this answer?
From a point A, the length of a tangent to a circle is 8cm and distance of A from the circle is 10cm. The length of the diameter of the circle is
a)
6 cm
b)
12 cm
c)
16 cm
d)
14 cm
|
|
Himaja Ammu answered |
Angle APO=90[radius is always perpendicular to the tangent)]
now by Pythagoras theorem AO^2=AP^2+OP^2
10^2=8^2+OP^2
OP^2=36
OP=6cm
here OP is nothing but the radius of circle
we know diameter is twice the radius...so
diameter=(2×6)=12 cm
now by Pythagoras theorem AO^2=AP^2+OP^2
10^2=8^2+OP^2
OP^2=36
OP=6cm
here OP is nothing but the radius of circle
we know diameter is twice the radius...so
diameter=(2×6)=12 cm
Two circles touch each other externally at C and AB is common tangent of circles, then ∠ACB is
- a)70°
- b)60°
- c)100°
- d)90°
Correct answer is option 'D'. Can you explain this answer?
Two circles touch each other externally at C and AB is common tangent of circles, then ∠ACB is
a)
70°
b)
60°
c)
100°
d)
90°
|
|
Nirmal Kumar answered |
Option d is correct because we know that tangents drawn from an external point to a circle make 90 degree at the point of contact
Number of tangents, that can be drawn to a circle, parallel to a given chord is- a)3
- b)Zero
- c)Infinite
- d)2
Correct answer is option 'D'. Can you explain this answer?
Number of tangents, that can be drawn to a circle, parallel to a given chord is
a)
3
b)
Zero
c)
Infinite
d)
2
|
Gaurav Kumar answered |
There are only two tangents that can be drawn parallel to a given chord. That is the tangents are drawn on either side of the chord so that both are parallel to the chord.
In the given figure, point P is 26 cm away from the centre O of a circle and the length PT of the tangent drawn from P to the circle is 24 cm. Then the radius of the circle is
- a)25 cm
- b)26 cm
- c)24 cm
- d)10 cm
Correct answer is option 'D'. Can you explain this answer?
In the given figure, point P is 26 cm away from the centre O of a circle and the length PT of the tangent drawn from P to the circle is 24 cm. Then the radius of the circle is
a)
25 cm
b)
26 cm
c)
24 cm
d)
10 cm
|
|
Dronacharya Institute answered |
∵ OT is radius and PT is tangent
∴ OT ⊥ PT
Now, in ΔOTP,
OP2 = PT2 + OT2
⇒ 262 = 242 + OT2
⇒ 676 - 576 -OT2
⇒ 100 = OT2 ⇒ 10 cm = OT
A circle is inscribed in ΔABC having sides 8 cm, 10 cm and 12 cm as shown in the figure. Then,
- a)AD = 7 cm, BE = 5 cm.
- b)AD = 8 cm, BE = 5 cm.
- c)AD = 8 cm, BE = 6 cm.
- d)AD = 5 cm, BE = 7 cm.
Correct answer is option 'A'. Can you explain this answer?
A circle is inscribed in ΔABC having sides 8 cm, 10 cm and 12 cm as shown in the figure. Then,
a)
AD = 7 cm, BE = 5 cm.
b)
AD = 8 cm, BE = 5 cm.
c)
AD = 8 cm, BE = 6 cm.
d)
AD = 5 cm, BE = 7 cm.
|
|
Arun Khatri answered |
Let AD = x and BE = y
∴ BD = 12 - x ⇒ BE = 12 - x [BD = BE = Tangents to a circle from an external point]
⇒ y = 12 - x ⇒ x+y = 12.......(i)
Also, AF = x and CF = 10 - x and CE = 8 - y
Also, AF = x and CF = 10 — x and CE = 8 - y
∴ 10 - x = 8 - yx - y = 2 (ii)
On solving eq. (i) and (ii), we get x = 7 and y = 5
⇒ AD = 7 cm and BE = 5cm
∴ BD = 12 - x ⇒ BE = 12 - x [BD = BE = Tangents to a circle from an external point]
⇒ y = 12 - x ⇒ x+y = 12.......(i)
Also, AF = x and CF = 10 - x and CE = 8 - y
Also, AF = x and CF = 10 — x and CE = 8 - y
∴ 10 - x = 8 - yx - y = 2 (ii)
On solving eq. (i) and (ii), we get x = 7 and y = 5
⇒ AD = 7 cm and BE = 5cm
The tangents drawn at the ends of a diameter of a circle are:- a)intersecting at a point inside the circle
- b)perpendicular
- c)intersecting at the centre of the circle
- d)parallel
Correct answer is option 'D'. Can you explain this answer?
The tangents drawn at the ends of a diameter of a circle are:
a)
intersecting at a point inside the circle
b)
perpendicular
c)
intersecting at the centre of the circle
d)
parallel
|
|
Rahul Kapoor answered |
Here AB is a diameter of the circle with centre O, two tangents PQ and RS drawn at points A and B respectively.
Radius will be perpendicular to these tangents.
Thus, OA ⊥ RS and OB ⊥ PQ
∠OAR = ∠OAS = ∠OBP = ∠OBQ = 90degree
Therefore,
∠OAR = ∠OBQ (Alternate interior angles)
∠OAS = ∠OBP (Alternate interior angles)
Since alternate interior angles are equal, lines PQ and RS will be parallel.
From a point X, the length of the tangent to a circle is 20 cm and the distance of X from the centre is 25 cm. The radius of the circle is- a)10 cm
- b)
- c)15 cm
- d)20 cm
Correct answer is option 'C'. Can you explain this answer?
From a point X, the length of the tangent to a circle is 20 cm and the distance of X from the centre is 25 cm. The radius of the circle is
a)
10 cm
b)
c)
15 cm
d)
20 cm
|
|
Priyanshu Intelligent answered |
Radius of the circle = √((25*25) - (20*20))
= √(625-400)
=√225
=15.
Radius = 15 cm.
Hence option c is correct.
= √(625-400)
=√225
=15.
Radius = 15 cm.
Hence option c is correct.
If ΔABC is circumscribing a circle in the Fig. 8.12. The length of AB is
- a)12 cm
- b)13 cm
- c)9 cm
- d)14 cm
Correct answer is option 'D'. Can you explain this answer?
If ΔABC is circumscribing a circle in the Fig. 8.12. The length of AB is
a)
12 cm
b)
13 cm
c)
9 cm
d)
14 cm
|
|
Kuldeep Kuldeep answered |
See, as you can see the figure friend, you can see the Triangle with the circumscribed circle and they given some values to find right. So, now, as per the question, we should find the value for AB. So,
As you have studied the theorem of the chapter circle, Apply the theorem.
"The length of tangents drawn from an external point to a circle are equal".
Given:-
BG = 6cm , GC = 4cm , AC = 12cm , AB =?
Here, in this triange, BG = 6cm. So, BF is also 6cm as it is both tangents of a circle. So,
BG (6cm) = BF (6cm).
GC = 4cm, So CE is also 4cm as it is also a tangent of a circle. So,
GC (4cm) = CE (4cm).
Total length of AC is 12cm. So, we got CE = 4cm. We should find AE. Then do,
AE = AC - CE.
AE = 12 - 4.
AE = 8cm.
(Put the same value of AE for AF. Because, AF is also a tangent of a circle. So put AF = 8cm)
So now, we can find the value for AB.
AB = AF + FB.
AB = 8 + 6
AB = 14cm.
Therefore, the value of AB is 14cm. So the correct option is Option d.
Hope you have understand the answer and sorry for the brief explanation friend...
As you have studied the theorem of the chapter circle, Apply the theorem.
"The length of tangents drawn from an external point to a circle are equal".
Given:-
BG = 6cm , GC = 4cm , AC = 12cm , AB =?
Here, in this triange, BG = 6cm. So, BF is also 6cm as it is both tangents of a circle. So,
BG (6cm) = BF (6cm).
GC = 4cm, So CE is also 4cm as it is also a tangent of a circle. So,
GC (4cm) = CE (4cm).
Total length of AC is 12cm. So, we got CE = 4cm. We should find AE. Then do,
AE = AC - CE.
AE = 12 - 4.
AE = 8cm.
(Put the same value of AE for AF. Because, AF is also a tangent of a circle. So put AF = 8cm)
So now, we can find the value for AB.
AB = AF + FB.
AB = 8 + 6
AB = 14cm.
Therefore, the value of AB is 14cm. So the correct option is Option d.
Hope you have understand the answer and sorry for the brief explanation friend...
In the given figure, PT is tangent to the circle with centre O. If OT = 6 cm and OP = 10 cm then the length of tangent PT is
- a)6 cm
- b)15 cm
- c)18 cm
- d)8 cm
Correct answer is option 'D'. Can you explain this answer?
In the given figure, PT is tangent to the circle with centre O. If OT = 6 cm and OP = 10 cm then the length of tangent PT is
a)
6 cm
b)
15 cm
c)
18 cm
d)
8 cm
|
Learning Education answered |
In right triangle PTO By using Pythagoras theorem,
PO2 = OT2 + TP2
⇒ 102 = 62 + TP2
⇒ TP2 = 100 - 36
⇒ TP2 = 64
⇒ TP = 8
At one end of a diameter PQ of a circle of radius 5 cm, tangent XPYis drawn to the circle. The length of chord AB parallel to XY and at a distance of 8 cm from P is- a)6 cm.
- b)5 cm.
- c)7 cm.
- d)8 cm
Correct answer is option 'D'. Can you explain this answer?
At one end of a diameter PQ of a circle of radius 5 cm, tangent XPYis drawn to the circle. The length of chord AB parallel to XY and at a distance of 8 cm from P is
a)
6 cm.
b)
5 cm.
c)
7 cm.
d)
8 cm
|
Prasad Chavan answered |
Here, OP = 00 = 5 cm [Radii]
And OR = PR - OP = 8 - 5 = 3 cm Also, OA = 5 cm [Radius]
Now, in triangle AOQ, OA2 = OR2 + AR2 ⇒ 52 = 32 + AR2
⇒AR2 = 25-9= 160 AR= 4cm
Since, perpendicular from centre of a circle to a chord bisects the chord.
∴ AB = AR+ BR = 4+ 4 = 8cm
And OR = PR - OP = 8 - 5 = 3 cm Also, OA = 5 cm [Radius]
Now, in triangle AOQ, OA2 = OR2 + AR2 ⇒ 52 = 32 + AR2
⇒AR2 = 25-9= 160 AR= 4cm
Since, perpendicular from centre of a circle to a chord bisects the chord.
∴ AB = AR+ BR = 4+ 4 = 8cm
The length of tangent PQ, from an external point P is 24 cm. If the distance of the point P from the centre is 25 cm, then the diameter of the circle is
- a)7 cm
- b)14 cm.
- c)15 cm.
- d)12 cm
Correct answer is option 'B'. Can you explain this answer?
The length of tangent PQ, from an external point P is 24 cm. If the distance of the point P from the centre is 25 cm, then the diameter of the circle is
a)
7 cm
b)
14 cm.
c)
15 cm.
d)
12 cm
|
Swara Chopra answered |
Here ∠OPQ = 90°[Angle between tangent and radius through the point of contact]
∴ OQ2 = OP2 + PQ2 (25)2 = OP2 + (24)2 ⇒ OP2 = 625 - 576 ⇒ OP2 = 49
⇒ OP = 7 cm
Therefore, the diameter = 2 x OP = 2 x 7 = 14 cm
∴ OQ2 = OP2 + PQ2 (25)2 = OP2 + (24)2 ⇒ OP2 = 625 - 576 ⇒ OP2 = 49
⇒ OP = 7 cm
Therefore, the diameter = 2 x OP = 2 x 7 = 14 cm
In the figure, the pair of tangents AP and AQ, drawn from an external point A to a circle with centre O, are perpendicular to each other and length of each tangent is 4 cm, then the radius of the circle is
- a)10 cm
- b)4 cm
- c)7.5 cm
- d)2.5 cm
Correct answer is option 'B'. Can you explain this answer?
In the figure, the pair of tangents AP and AQ, drawn from an external point A to a circle with centre O, are perpendicular to each other and length of each tangent is 4 cm, then the radius of the circle is
a)
10 cm
b)
4 cm
c)
7.5 cm
d)
2.5 cm
|
|
Arun Yadav answered |
Join OA.
Triangles OPA and OQA are congruent.
⇒∠PAO = ∠QAO = 45o
Tangent and radius are perpendicular at the point of contact.
∠OPA = 90o
⇒∠OAP = ∠AOP = 45o
⇒OP = AP = 4cm
So the radius of the circle is 4 cm.
PT is a tangent from an external point P and PAB is a secant. If PT = 6cm and PA = 3cm, then the length of PB is __- a)6
- b)36
- c)12
- d)2
Correct answer is option 'C'. Can you explain this answer?
PT is a tangent from an external point P and PAB is a secant. If PT = 6cm and PA = 3cm, then the length of PB is __
a)
6
b)
36
c)
12
d)
2
|
|
Rahul Kapoor answered |
We know that:
PT^2 = PA X PB
therfore PB = PT^2/PA = 36/3 = 12
Chapter doubts & questions for Circles - Online MCQ Tests for Class 10 2025 is part of Class 10 exam preparation. The chapters have been prepared according to the Class 10 exam syllabus. The Chapter doubts & questions, notes, tests & MCQs are made for Class 10 2025 Exam. Find important definitions, questions, notes, meanings, examples, exercises, MCQs and online tests here.
Chapter doubts & questions of Circles - Online MCQ Tests for Class 10 in English & Hindi are available as part of Class 10 exam.
Download more important topics, notes, lectures and mock test series for Class 10 Exam by signing up for free.
|
© EduRev
|
Education Revolution
|
|
Signup on EduRev and stay on top of your study goals
10M+ students crushing their study goals daily
